Coil Handling Intelligent Overhead Crane
Our Coil Handling Intelligent Overhead Crane is a factory-direct lifting solution designed for efficient and safe coil handling, overhead crane systems, and modern material handling operations in large-scale industrial facilities. Manufactured with strict quality control and advanced automation technology, it delivers reliable performance, precise positioning, and long-term durability under continuous operation. Complete mechanical drawings and technical documentation are available to support equipment integration and project planning. The crane adapts to diverse production and logistics environments, effectively solving issues such as heavy coil lifting, damage prevention, workflow inefficiency, and operator safety risks. With guaranteed after-sales service, professional technical support, and dedicated personnel tracking production and orders from manufacturing to delivery, we ensure smooth procurement, stable operation, and maximum value for customers worldwide.
- Source factory design and customization
- High-quality multi-layer monitoring
- Worry-free after-sales service and reliable cooperation
- Expert remote online guidance
- A team of engineers with decades of experience
- Professional mechanical drawing services are available
Coil Handling Intelligent Overhead Crane
Factory-Direct Smart Coil Lifting Solution ForIntelligent Overhead Crane for Coil Handling
As a factory-direct crane manufacturer with deep experience in automated material handling,
we designed the Coil Handling Intelligent Overhead Crane to meet the exacting needs of steel coil yards,
slitting and rewinding lines,coil warehouses,and automated logistics hubs.
The system combines vision/RFID coil identification,programmable path planning,soft-lift control,dynamic anti-sway,
and integrated safety supervision to protect coil integrity,speed up handling cycles,
and reduce manual intervention for mills and service centers worldwide.
Integrated intelligent functions(auto-identify,auto-storage,anti-sway control,VFD servo drives and PLC orchestration)
make this crane a preferred choice for buyers searching for a factory-direct coil crane,
OEM coil handling solution,smart coil lifting system,or automated coil logistics equipment.
Product Introduction
The Coil Handling Intelligent Overhead Crane is engineered for continuous,high-throughput coil operations.
It supports vision and RFID recognition,automatic positioning with±10–20 mm accuracy in auto mode,soft-start/soft-stop lift profiles,
and path anti-collision logic.Built on a stiff,lightweight European-style girder,
the crane pairs energy-efficient VFD/servo drives with purpose-built coil lifters—magnetic beams,
C-hooks,or vacuum-assisted clamps—so the same platform serves hot-rolled,cold-rolled,stainless,
and aluminium coils with minimal changeover.
What Problems Can This Crane Solve?
Prevents coil edge damage and shape distortion through soft-lift and controlled acceleration profiles.
Eliminates manual ID and reduces sorting errors by vision/RFID-based automatic coil recognition.
Improves throughput in narrow-aisle,high-density coil storage with precise auto-positioning and compact girder design.
Reduces labor and safety risks during coil transfer,slitting feed,and distribution.
Enables digital factory workflows via MES/WMS integration and traceable coil movement logs.
Product Advantages
Smart Identification&Traceability
Vision and RFID systems automatically read coil ID,diameter,weight,and destination;data syncs with MES/WMS for traceability and inventory control.
Precision Auto-Positioning&Anti-Sway
PLC-driven path planning and anti-sway algorithms keep coils stable during high-speed moves and narrow-aisle maneuvers.
Coil-Specific Lifting Tools
Interchangeable lifters:magnetic coil beams for ferrous coils,cushioned C-hooks for inner-diameter lifting,and vacuum/clamp hybrids for delicate surfaces.
Energy-Efficient Drive&Regeneration
Low-noise motors,high-efficiency VFDs/servo drives and regenerative braking reduce energy consumption during frequent starts/stops.
Factory-Direct Customization&Support
OEM options include customized lifter designs,span/height ranges,automation levels(semi-auto→full-auto),control cabinet configurations,
and integration services for distributors and system integrators.
Technical Specifications
| Item | Specification |
| Capacity Options | 5 t/10 t/15 t/20 t/25 t/30 t/Custom |
| Span Range | 6 m–35 m(customizable) |
| Lifting Height | 6 m–28 m(customizable) |
| Working Duty | A5–A7 |
| Lifting Speed | 0.5–18 m/min(VFD/servo stepless) |
| Trolley Travel Speed | 2–45 m/min(VFD) |
| Crane Travel Speed | 3–80 m/min(VFD/servo) |
| Positioning Accuracy(Auto) | ±10–20 mm |
| Identification | Vision/RFID/Combined |
| Lifting Tools | Magnetic Beam/C-Hook/Clamp/Vacuum Hybrid |
| Control System | PLC+HMI/Touch Panel/Remote/MES/WMS Interface |
| Protection | IP54/IP55/IP65 options |
| Power Supply | 380V/400V/415V/440V,50/60Hz |
(Custom OEM configurations for coil lifters,automation packages,and control cabinets available.)
Applications
High-density steel coil warehouses and distribution centers
Slitting,rewinding and cut-to-length production lines
Hot-rolled,cold-rolled and stainless coil handling yards
Automated coil feeding and dispatch systems for service centres
Integrated coil logistics in metallurgical plants and steel mills
Why Choose Us?
Q1:What makes your coil crane different from standard overhead cranes?
We deliver a factory-direct intelligent coil solution that combines vision/RFID ID,coil-specific lifters,soft-lift profiles,and MES/WMS integration—engineered for coil protection and high-throughput yard operation.
Q2:Can you supply different lifter types for various coil materials?
Yes.We supply magnetic beams for ferrous coils,cushioned C-hooks,clamp/vacuum hybrids for delicate surfaces,and custom lifters per OEM requirements.
Q3:Is full automation supported?
Yes—systems range from remote-assisted semi-automatic to fully automated fleet operation with coordinated multi-crane scheduling and database-driven storage logic.
Q4:How do you support global customers and distributors?
Factory-direct supply includes OEM customization,control cabinet documentation,remote commissioning support,software protocol mapping for MES/WMS,and long-term spare parts supply.
After-Sales Service
Remote technical guidance for installation,commissioning,and control tuning
Video-based troubleshooting,operation training,and software updates
Factory video tours and documentation for QA and distributor verification
Continuous support for MES/WMS integration,parameter optimization,and lifecycle upgrades
Long-term supply of OEM spare parts,coil lifters,control modules,and consumables
FAQ-Coil Handling Intelligent Overhead Crane
1.Can the crane automatically pick the right storage slot for each coil?
Yes.Integrated MES/WMS interface and automatic path planning enable auto-storage and retrieval with collision-avoidance logic.
2.What identification methods are supported for coil tracking?
Vision recognition,RFID tagging,or combined modes are supported to ensure reliable coil identification.
3.Can the lifter protect painted or coated coils from surface damage?
Yes.We offer cushioned contact lifters and vacuum/clamp hybrids designed to minimize surface contact and prevent marking.
4.Do you provide retrofit kits for existing cranes to upgrade to smart coil handling?
Yes.Retrofit packages include control cabinet upgrades,positioning sensors,ID systems,and modular lifter mounts for many legacy cranes.
